ELCB TESTER
A great feature is remote testing which enables the user to hold the test leads with both hands by locking the test button; measurement will automatically start when the main voltage is detected. The ELCB Tester the voltage to Earth electrodes or Protective conductors during RCD test, when applying test currents, at measurement using Earth in order to prevent electrical shocks cause by the damaged earth. Measurement will cease at 50V AC or more. Intrinsically safe version is available ELCB Tester. With our expertise and trustworthiness, we are engaged in offering an optimum quality range of ELCB Tester. We are one of leading ELCB Tester Supplier.
Accessories:
- Pouch for leads
- AA Batteries
- 1 x Test Leads
- Instruction Manual
- Strap Belt
- 1 x (red & Black cords)
- 1 x Test Lead with Alligator clips
Categories
Other Details:
- ELCB Tester Conducting testing of rated residual non-operating currents at × 1/2 Range, measuring RCD trip time at × 1 and × 5 Ranges.
- Measurement of trip out current Measuring trip out current by varying current automatically.
- Remote Test Enabling a user to hold the Test Leads with his both hands by locking the Test Button. Measurement will automatically start when the main voltage is detected.
- Voltage Measurement Carrying out a constant measurement of voltage in the stand-by mode at each Range.
- Auto-detection of Contact Voltage Detecting the voltage to earth of Earth electrodes or Protective conductors during RCD test – when applying test currents – at measurement using EARTH in order to prevent electrical shocks caused by the damaged earth. Measurement will be ceased at AC50V or more.
- Dust- and Water-proof Dust- and Water-proof construction (designed to IEC 60529 IP54).
- Backlight Facilitating working at dimly illuminated locations.
Product Description
- Lines x 16 Characters L.C.D.
- Very Low Power Consumption.
- Microprocessor Controlled.
- Menu Driven.
- Accurate digital readout of disconnection Time.
- Automatic data hold function.
- o Zero Crossing Circuitry permit testing at 0 or 180 .
- Disconnection Phase Polarity shown on L.C.D. Display.
- Auto-Off and Off override.
- Polarity Trip indicator (Positive or Negative Phase).
- Wiring polarity indicator. Measure voltage and frequency between Line and Earth before testing.
- EN 61010-1 CAT III 240V.
